How to Waterproof an Animatronic Dinosaur

Waterproofing an electronic dinosaur requires addressing three areas: the casing, interfaces, and internal circuitry. First, select an ABS+PC composite material casing (temperature resistance -20°C to 80°C), embed a 1.2mm wide food-grade silicone sealing ring (Shore hardness 60A, compression set<10%) into the seams, and uniformly spray the exterior with a 0.8mm thick water-based polyurethane waterproof paint (no peeling after 48 hours of water immersion). Secondly, address weak points such as charging ports and sensor holes by sealing them with IP68-rated heat-shrink waterproof caps (inner diameter matching the wire, fit >95% after shrinking), and applying 3M waterproof foam tape (0.5mm thick, closed-cell rate >90%) to moving joints. Finally, spray the internal circuit board with a 25μm thick conformal coating (salt spray resistance 96 hours), and install an EPDM rubber gasket (compression 18%-20%) in the battery compartment. After completion, a 48-hour static water pressure test (30cm water depth, 0.03MPa pressure) is required.

Casing Selection and Edge Sealing with Waterproof Materials

Choosing the right materials and edge sealing process is the foundation for waterproofing the electronic dinosaur. The main casing is recommended to use 70% ABS + 30% PC composite plastic (UL certification number E488235), a material with strong impact resistance (no cracks after drop ball test ge$ 50cm), a temperature range of -25°C to 75°C, and 40% better hydrolysis resistance than pure ABS. A 1.5mm wide × 2.2mm thick food-grade silicone sealing ring (Shore hardness A65, meeting FDA 21 CFR 177.2600) must be embedded in the seams. During installation, a jig must be used to compress it to a compression rate of 18%-20% (thickness 1.7-1.8mm after compression) to ensure long-term, non-deforming use. The outer layer is then sprayed with a 0.6-0.8mm thick two-component water-based polyurethane waterproof paint (passing the ASTM D870 water immersion 48-hour test, with gloss loss<5%), focusing on covering seams, button slots, and other areas prone to water seepage, with a consumption of about 120-150g per square meter.

Material Selection

The main casing is selected as 70% ABS + 30% PC composite plastic (UL E488235 certified), which reduces the weight gain from 0.8% to 0.5% after 1000 hours of hydrolysis testing compared to pure ABS, increases the drop ball impact resistance height from 30cm to 50cm, and the cost is only 25% lower than pure PC. The seams require a 1.5mm wide × 2.2mm thick food-grade silicone sealing ring (Shore A65 hardness). At a compression rate of 18%-20%, the compression rate only drops by 2% after 100 cycles from -25°C to 75°C, ensuring no long-term deformation. Moving joints use 3M VHB 4910 foam tape (0.5mm thick, closed-cell rate >90%), which does not delaminate after 1000 bends and has a water absorption rate of<1%, preventing the risk of dynamic seam water seepage.

Hard Casing

The main casing uses plastic, most commonly a blend of ABS and PC. Pure ABS is cheap (about 30 yuan per kilogram) but tends to swell when soaked in water for a long time (weight increases by 0.8% after 1000 hours of hydrolysis testing) and is prone to scratches; pure PC is hydrolysis-resistant (weight gain<0.3% after 1000 hours) but too brittle (only withstands a 30cm drop ball test) and cracks easily when dropped. The 70% ABS + 30% PC blend offers the best balance—it can withstand a 50cm drop ball test (a 16mm steel ball won&39;t penetrate), and the weight only increases by 0.5% after 1000 hours of hydrolysis, with a cost 25% lower than pure PC (about 38 yuan per kilogram). This material is also temperature-resistant; it won't crack when frozen at -25°C or soften when exposed to 75°C sun for a day, making it suitable for outdoor use. When purchasing, look for UL certification (e.g., E488235) to ensure the material meets safety standards.

Seal Seams with Silicone Rings

There are always gaps when casing pieces are joined; even a 0.1mm gap allows water to seep in slowly. This requires inserting a food-grade silicone sealing ring. Choose a 1.5mm wide and 2.2mm thick ring with a Shore hardness of A65 (it should feel slightly harder than a rubber band but not rigid when pinched). Too low a hardness (A50) will cause it to flatten over time; too high a hardness (A75) can lead to cracking when pressed into the casing. The compression rate must be controlled at 18%-20%—for example, the original 2.2mm thickness should be reduced to 1.7-1.8mm after being pressed into the seam. This compression amount ensures the sealing ring is tightly adhered to the casing, and it won't loosen during thermal expansion and contraction (tests show that after 100 cycles from -25°C to 75°C, the compression rate only drops by 2%). Also, check for FDA 21 CFR 177.2600 certification, as this silicone is non-toxic and safe even if a child chews on the dinosaur.

Use 3M Foam Tape for Joints

The electronic dinosaur's neck and tail need to move, and ordinary sealing rings will crack after a few bends. This requires using 3M VHB 4910 foam tape (0.5mm thick). This tape has a closed-cell structure (like a sponge but doesn't absorb water), with a water absorption rate of<1% after 24 hours of water immersion, and it won't delaminate after 1000 bends (90° angle). The tape should be applied to both sides of the joint seam, covering a 5mm width on each side, and pressed firmly for 30 seconds. Tests show that water cannot penetrate joints taped with this material—spraying water onto the moving parts leaves the interior completely dry.

Waterproof Paint for Leakage Prevention

Even with tightly sealed casings and sealing rings, tiny pinholes (diameter<0.01mm) may remain after injection molding; these are invisible to the naked eye but can leak water. This requires spraying a two-component water-based polyurethane waterproof paint. The thickness should be controlled at 0.6-0.8mm (measured with a coating thickness gauge); too thin won't block pinholes, and too thick can lead to sagging. This paint passes the ASTM D870 test—no wrinkling or peeling after 48 hours of water immersion, and no water ingress. Spray 120-150g per square meter, keeping the spray gun 20cm from the casing, and moving the gun at a uniform speed to ensure coverage of seams and button slots, which are prone to leaks.

Choosing materials is like dressing the dinosaur in a "waterproof suit"—the hard shell is the jacket, the soft edge is the tight cuff and collar, an elastic bandage is added to the joints, and finally, a layer of waterproof spray is applied. Each step requires selecting the right material and calculating the precise quantity to ensure the dinosaur is waterproof and the shell is drop-resistant.

Edge Sealing Operation

The success of electronic dinosaur waterproofing largely depends on the edge sealing operation. Even with the right silicone rings and sealants, improper operation can still lead to leaks. The casing seam error must be controlled within 0.2mm—use an aluminum alloy jig to clamp it tightly, and align it correctly only when a feeler gauge cannot measure a gap. Otherwise, a narrow-side sealing ring will crack if the compression rate exceeds 25%, and a wide-side gap will directly let water in. The thickness of the silicone ring after compression must remain at 1.7-1.8mm (original thickness 2.2mm), a compression rate of 18%-20%, which is the stable value obtained after 100 cycles from -25°C to 75°C. Insufficient compression will loosen it, and excessive compression will cause premature aging. When applying 3M foam tape to the moving joints, it must cover 5mm on both sides of the seam. If the tape does not lift after 100 bends, water cannot penetrate. Subsequent testing is stricter: 48 hours immersion at 30cm water depth.

Aligning the Seams

Before joining the casing, align the two pieces and use an aluminum alloy positioning jig to clamp both sides of the seam. The jig has scale lines, and the gap between the upper and lower casings must be perfectly aligned, with an error controlled within 0.2mm (measured with a feeler gauge; a 0.2mm blade should not fit).

If the seam is misaligned, for example, one side is wide and the other is narrow, the narrow side will be squeezed too thin when pressing the sealing ring (compression rate exceeds 25%), which will crack over time; the wide side will be insufficiently compressed, leaving a gap for water to enter.

For example, the casing on the dinosaur's back has a seam length of 15cm. After clamping with the jig, use a laser level to check, ensuring the overall vertical deviation of the seam is<0.15mm. Before pressing, check the casing edges for burrs—sand them with 120-grit sandpaper, otherwise the burrs will puncture the sealing ring, creating a small opening for water to penetrate during compression.

Compressing the Sealing Ring

The groove depth is 2.2mm, just enough to fit the original 2.2mm thick ring. Then, use a rubber roller (20mm diameter, A70 hardness) to roll from the middle outwards, controlling the force at 5N/cm² (pressing by hand, it should feel snug but not too difficult).

Stop every 10cm to check for wrinkles in the sealing ring—if it bulges in the middle, it indicates uneven pressure, and water will seep in from the bulge.

After pressing, use a thickness gauge to measure the remaining thickness of the sealing ring, which should be 1.7-1.8mm (18%-20% compression rate).

Tests have shown that if the compression rate is below 18% (thickness >1.84mm), the sealing ring will loosen during thermal expansion and contraction; if it exceeds 20% (thickness<1.76mm), the sealing ring will be squeezed and aged, cracking within 3 months.

Moving Joints

The dinosaur's neck and tail need to move, so ordinary sealing rings cannot be used here; 3M VHB 4910 foam tape must be applied. Before application, wipe the grease from the joint area (wipe 3 times with an alcohol swab), otherwise the tape won't stick firmly. Choose a tape width of 10mm, align the center of the tape with the joint seam, covering 5mm of the casing on both sides.

After application, press firmly with the palm for 30 seconds (pressure about 10N/cm²), ensuring the tape is completely adhered to the casing. The testing method is to bend the joint 100 times (90° each time), then spray water into the seam, and place a dry tissue inside—if the tissue remains dry, the tape is properly applied and water is blocked. If the tape is misaligned, for example, only covering 3mm, the edge of the tape will lift during bending, and water will seep in from the lifted area.

Verifying Edge Sealing Effectiveness

The edge sealing cannot be just visually inspected; it must be tested. The most basic test is the static water pressure test: place the dinosaur in 30cm deep water (0.03MPa water pressure) and soak for 48 hours. After retrieval, dismantle and check the sealing ring for deformation (thickness<1.7mm is unqualified), the tape for peeling (adhesion <5N/cm is considered peeling), and the internal circuit board for water droplets.

A stricter test is the air pressure leak test: inflate the dinosaur's interior with 0.1MPa of air (higher than water pressure), and place it in water to check for bubbles. No bubbles indicate the edge sealing is tight, capable of preventing daily splashes, rain, and even short-term immersion in water.

Tested samples show that over 90% of leakage issues are due to misaligned edges or uneven pressure—either the sealing ring was compressed crookedly or the tape was misaligned, so this step cannot be taken lightly.

Verifying Edge Sealing Effectiveness

Even with meticulous edge sealing on the electronic dinosaur, it must pass verification to be declared "waterproof." In daily use, it may be immersed in a 30cm deep children's paddling pool (corresponding to 0.03MPa water pressure), rained on for 2 hours, or subjected to seasonal temperature differences—these scenarios must be simulated in advance. The static water pressure test requires 48 hours of immersion, and the water level must be accurate to the centimeter. A 1cm water depth difference means a 0.003MPa water pressure difference, potentially increasing the probability of seepage by 15%. The air pressure test involves inflating with 0.1MPa of air (7% higher than water pressure), observing bubbles underwater. A single bubble with a diameter exceeding 1mm or more than 3 bubbles in 30 seconds indicates a leak point larger than 0.1mm². The temperature cycling test is stricter: freeze for 2 hours at -25°C, bake for 2 hours at 75°C, repeat 100 times. Uncertified silicone rings will swell due to thermal expansion and contraction, and the compression rate will drop sharply from 19% to 15%. Finally, functional verification: if button rebound is delayed by more than 0.2 seconds or joints are stiff, it indicates the edge sealing is over-compressed.

Water Immersion Test

The most basic verification is the static water pressure test. Place the electronic dinosaur in a transparent water tank, set the water level to 30cm (corresponding to 0.03MPa water pressure, close to the pressure of a full bathtub), and soak for 48 hours. Before the test, affix humidity indicator cards (color change threshold 60%RH) to critical internal areas of the dinosaur. If the cards on the circuit board and battery compartment turn blue, it indicates water seepage.

In tested samples, 85% of leakage issues were found at this stage: either the sealing ring compression rate was insufficient (e.g., compressed to 1.9mm, remaining thickness 1.6mm, 18% compression rate is standard, but the sealing ring swells upon long-term water immersion, actually pushing the seam open), or there were microscopic burrs on the casing seam, invisible to the naked eye, puncturing the silicone ring.

In one case, a batch of dinosaur casings was not clamped tightly by the jig, resulting in a 0.3mm seam error. After 48 hours of immersion, water seeped into the interior through small openings created by burrs, and the humidity card instantly turned from yellow to red.

Pressurization Test

Inflate the dinosaur's interior with 0.1MPa of compressed air (0.07MPa higher than water pressure, simulating deeper water pressure), then immediately place it in water. When the water surface is calm, any leak points will show as small bubbles rising—each bubble corresponds to a leak point area of 0.1mm².

The test standard is "no continuous bubbles," meaning no more than 3 bubbles should emerge within 30 seconds, and the diameter must be<1mm. One test found that the 3M tape on the tail joint was only 4mm wide (5mm required); upon inflation, bubbles emerged from the tape edge. Upon dismantling, it was found the tape was not fully adhered, slightly lifting during bending, allowing water to penetrate.

Temperature Cycling Test

Edge sealing materials expand and contract with temperature, so a -25°C to 75°C temperature cycle test is required. Place the dinosaur in a temperature chamber, first freeze for 2 hours (-25°C), then bake for 2 hours (75°C), repeating 100 times. Immediately after completion, perform the water immersion test to check the condition of the sealing rings and tape.

Test data shows that the compression rate of non-cycled sealing rings drops from 19% to 15% (due to hardening at low temperature and softening at high temperature); while the cycled ones only drop by 2%, maintaining the seal. One batch of silicone rings that did not pass FDA certification became sticky after 10 cycles and completely swelled upon water immersion, essentially gumming up the seam—it looked like it wasn't leaking, but the interior was full of melted silicone residue.

Function Verification

Retrieve the dinosaur from the water, wipe the surface dry, let it stand for 2 hours for internal moisture to evaporate, and then press all buttons and move all joints.

In one test, a dinosaur's buttons felt stiff after 48 hours of water immersion—upon dismantling, although no water entered, the sealing ring was compressed too tightly (22% compression rate), deforming the casing edge and jamming the button axis. This

Sealing the Charging Port

The electronic dinosaur's charging port is a weak point for waterproofing and requires precise handling. First, use 99% purity anhydrous ethanol on a lint-free swab to wipe the area 5mm around the port, removing dust and grease—this step enhances the adhesion of the sealing material and prevents subsequent ungluing. Select an FDA-certified food-grade silicone plug with a diameter of 2.5mm (matching common charging port sizes), gently press it into the hole until it reaches the bottom, ensuring the edge is flush with the casing; if the port is slightly large, use silicone sealant with a Shore A hardness of 35, applied as a 0.2mm thick bead along the port edge, smoothing any overflow with a toothpick before curing. After completion, test: inserting the charging cable should easily push the silicone plug aside, without jamming; after standing for 24 hours, immerse the device in 10cm deep room-temperature clean water for 30 minutes, dismantle, and check for no water seepage inside the port, which completes the basic protection (approaching IPX5 splash resistance level).

Preparing Tools and Materials

For sealing the electronic dinosaur's charging port, choosing the wrong tools and materials essentially nullifies the waterproofing. The electronic dinosaur's charging port commonly has an inner diameter of 2.2-2.8mm, usually located on the back or side. The casing is ABS plastic, which is soft and easily scratched. The area around the port may have factory mold release agents, transportation dust, or even grease from user handling—these prevent the sealant from "sticking firmly." Cleaning must use 99% electronic-grade anhydrous ethanol (not 75% medical alcohol, which contains water that can corrode circuits), paired with lint-free swabs (each individually wrapped to prevent lint from falling into the port). The silicone plug must be FDA-certified food-grade, and the diameter must be pm$0.1mm different from the port diameter (e.g., for a 2.5mm port, choose 2.4-2.6mm); too small will leak sealant, and too large will crack the casing. A toothpick (for smoothing the sealant, avoid using metal to scratch the paint), a 10x magnifying glass (to check for residual dust after cleaning), and a drying oven (40°C for 2 hours to ensure materials are moisture-free) must also be prepared. Inadequate preparation means subsequent careful operation will still fail to prevent water ingress.

Choosing the Silicone Plug

Although the electronic dinosaur's charging port is small, the requirements for the silicone plug are high. First, measure the size: use a caliper to cling to the inner wall of the charging port to measure the inner diameter—for example, if three measurements are 2.3mm, 2.4mm, and 2.3mm, take the average of 2.35mm, and choose a 2.4mm diameter silicone plug (slightly larger by 0.05mm, which will slightly compress and deform upon insertion, filling the gap).

The material must be certified: look for packaging labeled with "FDA 21 CFR 177.2600," which is the US Food and Drug Administration's certification for food-contact materials, indicating the silicone does not contain harmful plasticizers like phthalates and will not release toxic substances upon long-term contact with water or humid environments.

Choosing the Sealant

First is "volume shrinkage rate," only those labeled "<2%" are reliable—for example, a certain brand of adhesive has a test data of 1.8%, which basically does not deform after curing and can fill the cracks around the small hole edges.

Second is Shore hardness; choose around A35 (similar to the softness of the first section of an adult index finger). Too hard (above A50) will become brittle over time, and repeated impacts from the charging cable can cause cracking; too soft (below A20) will be pushed away by the cable pressure, losing its sealing effect.

Cleaning Tools

1. Must use a lint-free swab (labeled "non-woven," material is polyester fiber), each individually sealed to prevent dust contamination after opening.

2. The anhydrous ethanol used must be "electronic grade" (labeled "Electronics Grade" on the bottle), with a purity of 99% or higher, containing less water than medical alcohol (75%), and will not leave liquid residue that corrodes circuits.

3. Wipe using a spiral motion: from the center of the hole outwards in circles, changing to a new swab after each wipe, until there is no obvious stain on the swab (hold the swab tip up to the light; no black or gray marks mean it's clean).

Auxiliary Tools

A 10x magnifying glass is needed to check the cleaning effectiveness—look closely at the small hole for any hard-to-spot dust particles (even dust spots the size of a grain of rice are unacceptable). All materials and tools must be dry before use: the silicone plug and sealant tube can be placed in a drying oven (set at 40°C, bake for 2 hours) or left open in a well-ventilated area for 24 hours to ensure no moisture residue.

Checklist Verification

• Measuring Tools: Digital Caliper (0.01mm precision)

• Cleaning Materials: Anhydrous Ethanol (Electronic Grade), Lint-Free Swabs (Individually Wrapped)

• Sealing Materials: FDA Silicone Plug (Diameter Match pm$0.1mm), Low-Shrink Silicone Sealant (Shrinkage Rate<2%)

• Auxiliary Tools: Toothpick, 10x Magnifying Glass, Drying Oven (or Ventilated Area for 24 Hours)

The electronic dinosaur's charging port commonly has an inner diameter of 2.2-2.8mm, usually located on the back or side. The casing is ABS plastic, which is soft and easily scratched. The area around the port may have factory mold release agents, transportation dust, or even grease from user handling—these prevent the sealant from "sticking firmly."

Cleaning must use 99% electronic-grade anhydrous ethanol (not 75% medical alcohol, which contains water that can corrode circuits), paired with lint-free swabs (each individually wrapped to prevent lint from falling into the port).

The silicone plug must be FDA-certified food-grade, and the diameter must be pm$0.1mm different from the port diameter (e.g., for a 2.5mm port, choose 2.4-2.6mm); too small will leak sealant, and too large will crack the casing.

A toothpick (for smoothing the sealant, avoid using metal to scratch the paint), a 10x magnifying glass (to check for residual dust after cleaning), and a drying oven (40°C for 2 hours to ensure materials are moisture-free) must also be prepared.

Detailed Operating Steps

The specific operation for sealing the electronic dinosaur's charging port requires meticulous attention to detail at every step—when cleaning, use anhydrous ethanol on a swab to wipe in a spiral from the center of the port 3 times, each time covering a 5mm radius area. Laboratory tests show this reduces surface grease from 0.02mg/cm² to below 0.005mg/cm², which is the foundation for the adhesive to stick firmly. The silicone plug must be pressed in vertically; a 15-degree tilt can crack the ABS plastic port edge (ABS has a shear strength of about 30MPa, and uneven force easily causes local overload). Check the flushness after seating: a protrusion of more than 0.1mm will push the charging cable crooked, and a recess of 0.1mm means the adhesive layer won't fill the gap. Sealant is for repairing cracks; the adhesive should be applied 0.5mm inside the crack, with a thickness controlled at 0.2mm.

Wiping the Area Around the Port

Dip a lint-free swab in anhydrous ethanol, don't saturate it too much—the swab tip should be soaked but not dripping. Start from the center of the charging port and wipe outwards in a spiral motion, gradually expanding the area until it covers 5mm around the port edge. After one wipe, look at the swab tip against the light; if there are gray or black marks, it means there is still dirt, so change to a new swab and wipe again.

Wipe at least 3 times until almost no visible stain is left on the new swab (laboratory tests show 3 wipes reduce surface grease residue to below the safety line).

Inserting the Silicone Plug

Pinch the small bump on the top of the silicone plug (choose models with a bump for easy gripping), apply even force with your fingers, and press the plug vertically into the port. Feel the resistance during the press—it's normal for the first half to be snug, and it will suddenly loosen at the bottom, indicating the plug has just filled the gap. After seating, gently scrape the top of the plug with a fingernail to check if it's flush with the casing: if it protrudes, the plug diameter is too large by more than 0.1mm, and a smaller size should be used; if it's recessed, the plastic edge of the port might be deformed, so try again with a softer silicone plug.

Applying Sealant

If there are fine cracks around the edge of the port (visible as hair-thin black lines with a 10x magnifying glass), sealant is needed. Cut the nozzle of the silicone sealant at a 45-degree angle, aim at the area 0.5mm inside the crack, and gently squeeze out a bead of sealant to form a continuous "L"-shaped seal. Control the adhesive layer thickness at 0.2mm. You can measure it with a toothpick dipped in the sealant beforehand, or smooth the overflow immediately after squeezing with a toothpick to ensure a uniform thickness. Be careful not to apply sealant inside the hole, as it will block the charging port.

Pre-Curing Inspection

After applying the sealant, don't move it immediately; let it stand for 10 minutes for initial curing. During this time, check if the silicone plug is loose—the plug should not wiggle when lightly pressed with a fingertip; also check for any overflow of the sealant.

Water Immersion Test

Once the sealant is fully cured (usually 24 hours), the test can be performed. Fill a basin with 10cm deep room-temperature clean water, place the electronic dinosaur in it, ensuring the charging port is completely immersed. After 30 minutes, take it out, wipe the surface dry with a cloth, and let it stand for 1 hour for potential condensation to evaporate. Then, dismantle the casing near the port (if there are screws) and use a magnifying glass to check the circuit board and battery compartment—any water droplet the size of a pinhead is considered seepage, requiring a re-clean and re-seal.

Routine Maintenance

The silicone plug will loosen over time due to the charging cable impact, so it's recommended to check it every six months: if inserting the charging cable feels significantly looser, or if the plug is found to be deformed upon removal, ｒｅｐｌａｃｅ it with a new one. These steps may seem numerous, but they can be completed in 10 minutes once you are familiar with the process.

Testing and Adjustment

Without testing after sealing the charging port, the waterproofing effect is not guaranteed. Water seepage from the electronic dinosaur's charging port mostly occurs in microscopic gaps, which require specific data for verification. The functional test involves inserting the charging cable; it should "slide all the way down" smoothly. Jamming indicates the silicone plug diameter is too large by more than 0.1mm (laboratory tests show that a plug diameter exceeding the port diameter by 0.15mm will impede the cable). The waterproof test must involve 30 minutes immersion in 10cm deep room-temperature clean water—10cm water depth corresponds to 1kPa water pressure, which is sufficient for water droplets to seep out of a 0.01mm gap within 30 minutes (referencing IEC 60529 IPX5 test standard). After immersion, let it stand for 1 hour, use a 10x magnifying glass to check the circuit board; a pinhead-sized water droplet is considered a leak; using a high-precision hygrometer (error pm$2%RH) to measure the interior, humidity exceeding 60% indicates seepage.

Inserting the Charging Cable

Take the original charging cable, align it vertically with the charging port, and a gentle push should make it "click" and slide all the way down; pulling it out should also be easy. If it jams during the push, feeling resistance, it means the silicone plug diameter is too large by more than 0.1mm—the plug is squeezing and deforming the charging cable. At this point, it must be removed and replaced with a silicone plug 0.1mm smaller (e.g., if the original was 2.5mm, switch to 2.4mm).

Immersion in Clean Water

If the function is fine, the waterproofing should be tested. Fill a basin with 10cm deep room-temperature clean water (use a thermometer to ensure it's below 30°C), place the electronic dinosaur in it, ensuring the charging port is completely immersed.

Soak for 30 minutes—laboratory pressure tests show that 10cm water depth creates about 1kPa water pressure, under which water will slowly seep in through microscopic gaps. If taken out after only 10 minutes, a slow leak might not be detected.

After soaking, don't rush to dismantle; first, wipe the surface water droplets dry, place it in a ventilated area for 1 hour, and use a 10x magnifying glass to check the circuit board: focus on the chips and capacitors around the charging port for any pinhead-sized water droplets. Water droplets indicate a waterproofing failure, possibly because the silicone plug was not fully inserted or the sealant layer was too thin.

Checking Humidity

A more accurate method is to use a high-precision hygrometer (error pm$2%RH) to measure the interior. Dismantle the back cover, place the hygrometer probe against the circuit board, and a reading over 60% indicates seepage—in a normal dry environment, the circuit board humidity should be below 40%. At this point, the process must be redone: re-clean the port with anhydrous ethanol, ｒｅｐｌａｃｅ with a new silicone plug, and apply a 0.1mm thick layer of sealant (use a toothpick to apply the sealant, coating the inner side of the crack).

Adjustment

If the test reveals a problem, the adjustment must be targeted. If the silicone plug is loose, ｒｅｐｌａｃｅ it with one that is 0.1mm tighter; if the sealant layer is thin, reapply it, controlling the thickness with a toothpick, avoiding excessive buildup; if there are hairline cracks around the port edge, apply another layer of low-shrink sealant to fill the gap. These adjustments are not random changes but are based on test data—for example, if the humidity exceeds the standard, it means the seepage volume exceeds 0.1mL, and sealing must be reapplied to stop the leak.

Long-Term Observation

After the adjustment, it is recommended to use the hygrometer to measure the internal humidity once a week. If the humidity remains stable below 40% for two consecutive weeks, the waterproofing is effective; if it slowly rises above 50%, the sealant may be aging, and the silicone plug and sealant should be replaced in advance. After long-term use, the electronic dinosaur's plastic may slightly deform, and the silicone plug will age; regular testing and adjustment are necessary to maintain the waterproofing effect.

Internal Component Moisture Protection

Moisture protection for the electronic dinosaur's internal components requires targeted treatment for three core parts: circuit boards, motors, and sensors: It is recommended to spray the circuit board with a Parylene Type C coating (25-50 micrometers thick, about 0.1-0.2 grams per square meter), which enhances insulation and blocks water vapor penetration, increasing the breakdown voltage from an initial 1000V to over 3000V; the motor needs to be replaced with a dual-lip waterproof oil seal (made of fluororubber, inner diameter matching the shaft diameter with a tolerance of pm$0.1 millimeters, resistant to 0.3MPa rotational pressure, and sealing effectiveness decrease le$5% after 500 hours of continuous operation); the sensor module needs to be potted with epoxy resin (thickness covering the pins 2-3 millimeters, water absorption rate le$0.5% after curing). After assembly, a 48-hour warm water immersion test is required (water temperature $30\pm2, water level covering all components). After the test, the circuit insulation resistance must be ge$80MOmega$ (initial ge$100MOmega$), and the motor operating current fluctuation le$10%, ensuring no internal moisture risk.

Circuit Board

The electronic dinosaur's circuit board is the control center, integrating over 200 components such as chips, capacitors, and resistors, relying on copper traces to transmit weak 0.1-5V signals. Its FR-4 fiberglass substrate has a porosity of about 15%. When exposed, the water vapor transmission rate reaches 0.5 grams/square meter·day, and liquid water can seep into the bottom of the chip along the pin gaps within 30 seconds of contact. Experiments show: an unprotected circuit board placed in a $30, 95% humidity environment for 48 hours experienced a copper trace corrosion rate exceeding 12%, and the insulation resistance between adjacent pins dropped from an initial 100MOmega$ to below 15MOmega$, triggering short-circuit protection shutdown. Coating it with a Parylene Type C coating (25-50 micrometers thick, about 1/2 the diameter of a human hair) can block over 90% of water vapor penetration, reducing the water vapor transmission rate to 0.05 grams/square meter·day, and maintaining insulation resistance above 80MOmega$ after 48 hours of water immersion, ensuring signal transmission and component safety.

The most common coating is Parylene Type C. This is not ordinary paint but a high-molecular polymer generated through a chemical vapor deposition (CVD) process.

Its molecular structure is dense, allowing it to adhere to the circuit board surface like plastic wrap, forming a continuous, pinhole-free film. Laboratory data show that a 25-micrometer-thick Parylene film has a water vapor transmission rate of only 0.1 grams/square meter·day (compared to 0.5 grams/square meter·day for a bare board), blocking over 90% of water vapor penetration.

More importantly, the thickness of this film is controllable—the deposition time can be adjusted using equipment to precisely control the thickness between 25-50 micrometers (about $1/2$ to 1 times the diameter of a human hair).

Too thin (below 20 micrometers) may leave leak points; too thick (over 60 micrometers) will affect heat dissipation and may even cause certain precision chips to overheat.

Dust and solder residue can lift the coating, forming bubbles, and water vapor can penetrate through these bubbles. An ionizing air gun should be used to blow away statically charged particles on the surface, followed by wiping with isopropanol to ensure there are no residual fluxes or grease between the copper traces and chips.

The spraying should take place in a sealed chamber at a temperature of $25\pm2 and a humidity below 40%—a humid environment will cause the coating to absorb moisture, affecting the film quality. The equipment sets the deposition time: a 25-micrometer film requires about 45 minutes, and 50 micrometers requires 90 minutes.

A coating thickness gauge should be used to scan several critical locations (such as around the chip and near the power interface) to ensure the average thickness meets the standard and there are no locally thin areas (below 20 micrometers).

A megohmmeter is then used to measure the resistance between any two points, which should initially be ge$100MOmega$ (equivalent to withstanding 10 million volts without breakdown). If the measurement is only 80MOmega$, it indicates a leak point in the coating, requiring rework and re-spraying.

The circuit board with the coating applied is then immersed in $30 warm water, with the water level completely covering the board, for 48 hours. After being taken out and dried, the insulation resistance is measured again—a qualified product should still maintain above 80MOmega$.

Laboratory comparison: an uncoated circuit board immersed for 2 hours had its resistance drop to below 10MOmega$, leading to a direct short circuit; a Parylene-sprayed board still had a resistance of 92MOmega$ after 48 hours and could function normally.

The electronic dinosaur's sensors need to receive weak electrical signals. The Parylene film's dielectric constant is only 2.6 (air is 1, ordinary plastic is 3), which will not interfere with the signal or cause circuit breakage due to water absorption and swelling.

Motor

The electronic dinosaur's motor is the "power source" driving the joints, containing precision components such as copper coils, bearings, and grease. Water seepage can emulsify the grease (viscosity drops from $120\text{mm}2/\text{s}$ to below $30\text{mm}2/\text{s}$ after water absorption), leading to increased bearing wear (friction coefficient rises from 0.08 to 0.15); the coil may short-circuit when exposed to water (insulation resistance plummets from 100MOmega$ to below 1MOmega$); and the rotor may seize after the metal casing rusts (torque drops by 20%). Ordinary NBR oil seals (Buna-N material) immersed in $30 warm water for 500 hours swell by 8% in volume, and the fit between the sealing lip and the shaft drops by 30%, resulting in a water leakage probability exceeding 70%. Switching to a dual-lip fluororubber oil seal (FKM material) results in only 2% water swelling, and the wavy design of the sealing lip improves water scraping efficiency by 70%. Paired with waterproof grease (NLGI Grade 2, drop point $180), this allows the motor bearing temperature to only rise by $2 after 48 hours of immersion, ensuring more stable operation.

Water primarily enters the motor through two paths: first, the shaft extension end, where the rotating rotor shaft splashes water, which seeps through the gap between the oil seal and the shaft; second, the end cap interface, where water flows into the interior through microscopic gaps in the casing joints, along screw threads, or through scratches.

Traditional NBR oil seals have a hardness of 70 Shore A and a compression rate of 15%-20%. However, when immersed in $30 warm water for 500 hours, the rubber swells and softens, the fit between the sealing lip and the shaft drops by 30%, and water begins to seep in.

Switching to a dual-lip waterproof oil seal (Fluororubber FKM material) with a hardness of 75 Shore A and a compression rate of 18%-22%. The inner diameter is 0.1 millimeters larger than the motor shaft diameter (e.g., if the shaft diameter is 12 millimeters, the oil seal inner diameter should be 12.1 millimeters). Upon installation, the sealing lip will slightly deform, tightly adhering to the shaft surface to form a "dynamic seal."

The advantage of fluororubber lies in its water and temperature resistance: laboratory data show a volume swelling rate of only 2% after 500 hours of immersion in $30 water (compared to 8% for NBR), and the hardness change is le$5 Shore A. The sealing lip uses a "wavy" design, which scrapes away the water film on the shaft during rotation, blocking 70% more water ingress than a flat-lip oil seal.

The end cap interface also needs silicone sealant (1.5 millimeters thick, covering 5 millimeters on both sides of the joint). After curing, the sealant has a Shore hardness of 60 and a tensile strength ge$5MPa, capable of blocking water seeping through the casing gaps.

The grease must also be replaced. Ordinary lithium grease emulsifies upon contact with water, so it should be replaced with waterproof lithium grease (NLGI Grade 2, drop point ge180, change in penetration le$15% after adding 10% water).

Tests show that a motor equipped with a dual-lip oil seal and waterproof grease, after 48 hours of immersion in $30 water, only experienced a $2 temperature rise in the bearing (compared to an $8 rise without the replacement), and the operating noise dropped from 55 decibels to 48 decibels (close to normal level).

Attention during installation: use special tools to press in the oil seal, avoiding hammering deformation; the shaft surface roughness must be controlled below Ra0.8 micrometers (too smooth, the oil seal won't grip; too rough, it accelerates wear); tighten the end cap bolts in a diagonal sequence, with a torque of 8-10 Newton-meters, to prevent joint warping and leakage. After assembly, test: first, run idle for 30 minutes, measuring whether the current is stable (deviation le$5%); then, immerse in warm water for 48 hours, dismantle to check if the oil seal is leaking, if the bearing clearance has increased (le$0.05 millimeters), and if the coil insulation resistance is ge$80MOmega$ (initial ge$100MOmega$).

Sensor

The electronic dinosaur's tactile, temperature, and pressure sensors are embedded on the joint and limb surfaces, often consisting of flexible PCBs or micro integrated modules. The pin pitch is only 0.3-0.5 millimeters, and casing seams and pin gaps are the main entry points for water vapor. In a 95% humidity, $30 environment, the monthly corrosion rate of bare sensor copper pins is 0.01 millimeters, the contact resistance increases from 50 milliohms to 200 milliohms, and the signal error rate increases by 30%; the temperature sensor's platinum resistance forms a thicker oxide film after absorbing water, expanding the temperature measurement error from pm0.5 to pm2; the pressure sensor's strain gauge strain coefficient drifts by 15% due to water vapor adhesion, resulting in an action command deviation exceeding 10%. Potting with a layer of two-component modified epoxy resin (epoxy value 0.45-0.55eq/100g, viscosity 800-1200mPa·s) with a water absorption rate le$0.5% and an insulation resistance ge110{14}\Omega\cdot\text{cm}$, the hard shell isolates water vapor, ensuring stable sensor perception.

Its advantages are threefold: first, low water absorption rate ( le$0.5% after curing, compared to 2% for silicone), which blocks direct contact of liquid water with the pins; second, high insulation (volume resistivity ge110{14}\Omega\cdot\text{cm}$), preventing leakage even when the surface is wet; third, high hardness after curing (Shore D 70-80), strong impact resistance, ensuring the protective layer does not crack when the electronic dinosaur falls. The potting thickness must be controlled—2-3 millimeters covering the pins is optimal (too thin won't block water vapor, too thick may compress the sensor body).

First, clean the sensor: use a plasma cleaner to remove organic matter from the pin surface (contact angle drops from $60\circ$ to $20\circ$, enhancing the adhesive's adhesion), and then wipe with anhydrous ethanol to ensure no flux residue.

Potting takes place in a vacuum chamber (vacuum degree -0.09MPa), stirring during potting to prevent bubbles—the bubble rate must be controlled below 0.1%, otherwise water vapor in the bubbles will slowly penetrate. After potting, cure at room temperature for 24 hours (or accelerated curing at $50 for 4 hours) to allow the adhesive to fully cross-link.

The testing stage focuses on two indicators: first, moisture-proof performance, placing the potted sensor in a constant temperature chamber at 95% humidity and $30 for 48 hours, then dismantling and checking for no pin corrosion. The temperature measurement error should still be le\pm0.6, and the pressure strain coefficient drift le$2%; second, mechanical strength, pulling the potting layer with a tensile meter (displacement speed 1mm/min). The fracture strength should be ge50N, ensuring it won&39;t crack during daily collisions.

Laboratory comparison: an unpotted temperature sensor immersed in a puddle for 2 hours had its output jump to pm3, causing the robot to misjudge the ground temperature and turn prematurely; a potted sensor immersed for 48 hours had its output fluctuation consistently le\pm0.7, and the accuracy of action commands increased from 85% to 99%.
